Siemens SINUMERIK 802S User Manual

Technical Appendix
6.2 PLC user interface signals
6-139
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
HEX values (MD 14512 USER_DATA_HEX)
4500 Signals from NCK [r]
Data block
Interface NCK –––––> PLC
Byte
45001000 Hex value (BYTE)
45001001 Hex value (BYTE)
45001002 Hex value (BYTE)
45001003 Hex value (BYTE)
45001030 Hex value (BYTE)
45001031 Hex value (BYTE)
FLOAT values (MD 14514 USER_DATA_FLOAT)
4500 Signals from NCK [r]
Data block
Interface NCK –––––> PLC
Byte
45002000 Float value (REAL/ 4 bytes)
45002004 Float value (REAL/ 4 bytes)
45002008 Float value (REAL/ 4 bytes)
45002012 Float value (REAL/ 4 bytes)
45002016 Float value (REAL/ 4 bytes)
45002020 Float value (REAL/ 4 bytes)
45002024 Float value (REAL/ 4 bytes)
45002028 Float value (REAL/ 4 bytes)
