Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-112
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
21000
CIRCLE_ERROR_CONST
mm Circle end point monitoring constant POWER ON
_always 0.01 0.0 plus DOUBLE 2/7
22000
AUXFU_ASSIGN_GROUP
- Auxiliary function group (aux. fct. no. in channel): 0...49 POWER ON
_always 1 1 15 BYTE 2/7
22010
AUXFU_ASSIGN_TYPE
- Auxiliary function type (aux. fct. no. in channel): 0...49 POWER ON
_always , , - - STRING 2/7
22030
AUXFU_ASSIGN_VALUE
- Auxiliary function value (aux. fct. no. in channel): 0...49 POWER ON
_always 0 - - DWORD 2/7
22550
TOOL_CHANGE_MODE
- New tool compensation for M function POWER ON
_always 0 0 1 BYTE 2/7
27800
TECHNOLOGY_MODE
- Technology in the channel (value=0: milling, value=1: turning) NEW CONF
1 0 1 BYTE 2/7
6.1.4 Axis-specific machine data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
30130
CTRLOUT_TYPE
- Output type of setpoint (setpoint branch): 0 POWER ON
_always 0 0 2 BYTE 2/7
30200
NUM_ENCS
- Anzahl der Geber (1 oder kein Geber für die Spindel) RESTART
1 0 1 BYTE 2/7
30240
ENC_TYPE
- Type of actual value acquisition (actual position value) (encoder no.)
0: Simulation
2: Square-wave generator, standard encoder (pulse multiplication)
3: Encoder for stepper motor
POWER ON
_always 0, 0 0 4 BYTE 2/7
30350
SIMU_AX_VDI_OUTPUT
- Output of axis signals with simulation axes POWER ON
_always 0 *** *** BOOLEAN 2/7
30600
FIX_POINT_POS
mm, de-
grees
Fixed-value positions of axis with G75 (position no.) POWER ON
_always 0.0 - - DOUBLE 2/7
31000
ENC_IS_LINEAR
- Direct measuring system (linear scale) (encoder no.) POWER ON
_always 0 *** *** BOOLEAN 2/7
