Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-119
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
36710
DRIFT_LIMIT
% Drift limit value for automatic drift compensation NEW CONF
_always 1.000 0.0 plus DOUBLE 2/7
36720
DRIFT_VALUE
% Drift basic value NEW CONF
_always 0.0 DOUBLE 2/7
38000
MM_ENC_COMP_MAX_POINTS
- Number of intermediate points for interpolatory compensation (SRAM) POWER ON
_always 0, 0 0 5000 DWORD 2/7
6.1.5 Setting data
Number MD Name
Unit Name, Miscellaneous Activated
HW / function Standard value Minimum value Maximum value D type User
class
41110
JOG_SET_VELO
mm/min Axis speed for JOG Immediately
_always 0.0 0.0 plus DOUBLE 4/4
41200
JOG_SPIND_SET_VELO
rev/min Speed for spindle JOG mode Immediately
_always 0.0 0.0 plus DOUBLE 4/4
43210
SPIND_MIN_VELO_G25
rev/min Progr. spindle speed limitation G25 Immediately
_always 0.0 0.0 plus DOUBLE 4/4
43220
SPIND_MAX_VELO_G26
rev/min Progr. spindle speed limitation G26 Immediately
_always 1000 0.0 plus DOUBLE 4/4
43230
SPIND_MAX_VELO_LIMS
rev/min Spindle speed limitation with G96 Immediately
_always 100 0.0 plus DOUBLE 4/4
52011
STOP_CUTCOM_STORE
Alarm response for TRC and feedforward stop Immediately
- 1 0 1 BOOLEAN 4/4
