3-41
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Installing the STEPDRIVE C Drives
3.1 Installing and removing the STEPDRIVE C drive modules
!
Warning
Before installing the STEPDRIVE C drive modules, first always make sure that the equipment is disconnected
from the mains.
Installation
To install the drive modules, proceed as follows (see Fig. 3-1):
1. Screw in the upper fastening screws M5 with washer and lock washer.
2. Hang the module into the clips of the upper fastening bracket.
3. Screw in the lower fastening screws and tighten all screws.
Note
The modules should be installed such that a clearance of at least 10 cm is left above, below
and between the modules (dimension “a”).
The drive modules, however, can be mounted directly side by side (a> 10 mm) provided
they are ventilated with an air stream greater than / equal to 1 m/s.
Do not install devices which are strongly heated during operation beneath the drive modu-
les!
Removal
The drive modules are removed in the reverse order.
Warning
When removing the drive modules, always first make sure that the system is disconnected from the mains!
3
