Siemens SINUMERIK 802S User Manual

Installing the Control System
2.3 Connecting the individual components
2-34
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
2.3.8 Connecting the digital inputs and outputs (X2003 ... X2006)
Connector pin assignment
Interface for the digital inputs
Connector designation: X2003, X2004
IN
Connector type: 10–pin plug connector
Table 2-17 Connector pin assignment
X2003
Pin Name Type
1
2 DI0 I
3 DI1 I
4 DI2 I
5 DI3 I
6 DI4 I
7 DI5 I
8 DI6 I
9 DI7 I
10 M24 V
X2004
Pin Name Type
1
2 DI8 I
3 DI9 I
4 DI10 I
5 DI11 I
6 DI12 I
7 DI13 I
8 DI14 I
9 DI15 I
10 M24 V
Signal names
DI0...15 24 V digital inputs
Signal type
V Voltage input
I Input (24 V signal)
