Start-Up
4.6 Technology Setting
4-81
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
4.6 Technology Setting
Overview
The SINUMERIK 802S is supplied with the default machine data as a control system for tur-
ning machines (2 axes, 1 spindle). If you wish to set another technology (e.g. milling), the rele-
vant machine data file must be loaded from the tool box into the control system.
The file with the technology machine data must be loaded after the control system has booted
successfully, but prior to commissioning.
Sequence of operations
To change the technology setting, proceed as follows:
S Make a V24 link between PG/PC and the control system.
S Turn on the control system and wait until it has booted without errors.
S Press the Start data inp. softkey in the Services menu (use the V24 default interface set-
tings).
S Select the technology machine data file techmill.ini (included in the toolbox) required for
milling and transfer it to the PG/PC using WinPCIN.
S After the file has been transferred correctly, carry out POWER ON.
S The SINUMERIK 802S is now preset to the desired technology.
Example: techmill. ini
Default: 3 axes (X, Y and Z), 1 spindle, no transversal axis, G17 etc.
If you wish to reconfigure a SINUMERIK 802S control system to turning, carry out POWER
ON with the default machine data (start–up switch position 1).
Note
All memory areas are initialized or loaded with stored default values (machine data).
The basic configuration of the SINUMERIK 802C must be carried out during the commissio-
ning prior to the general configuration (MD input).
This need not to be done when series start–up is carried out. The configured machine data
are contained in the series start–up file.
