Installing the Control System
2.3 Connecting the individual components
2-27
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Table 2-7 Electrical parameters of the relay contacts
Parameter
Max. Unit
Switching voltage 50
V
Switching current 1 A
Switching power 30 VA
Cable length: max. 35 m
2.3.4 Connecting the spindle measuring system (X4)
Pin assignment of the connector on the ENC side
Measuring system interface (incremental encoder)
Connector designation: X4
ENCD
Connector type: 15–pin D-Sub female connector
Table 2-8 Pin assignment of the X4 female connector
X4
Pin Signal Type Pin Signal Type
1 9 M VO
2 10 N I
3 11 N_N I
8
15
4 P5_MS VO 12 B_N I
15
5 VO 13 B I
1
9
6 P5_MS VO 14 A_N I
1
7 M VO 15 A I
8
Signal names
A, A_N Track A (true and negated)
B, B_N Track B (true and negated)
N, N_N Zero mark (true and negated)
P5_MS +5.2 V supply
M Supply ground
