Siemens SINUMERIK 802S User Manual

Technical Appendix
6.1 List of machine and setting data
6-113
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
31010
ENC_GRID_POINT_DIST
mm Division period for linear scales (encoder no.) POWER ON
_always 0.01 0.0 plus DOUBLE 2/7
31020
ENC_RESOL
- Encoder markings per revolution (encoder no.) POWER ON
_always 2048 0.0 plus DWORD 2/7
31030
LEADSCREW_PITCH
mm Pitch of leadscrew POWER ON
_always 10.0 0.0 plus DOUBLE 2/7
31040
ENC_IS_DIRECT
- Encoder mounted directly to the machine (encoder no:) POWER ON
_always 0 *** *** BOOLEAN 2/7
31050
DRIVE_AX_RATIO_DENOM
- Denominator load gearbox (control parameter no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31060
DRIVE_AX_RATIO_NUMERA
- Numerator load gearbox (control parameter set no.): 0...5 POWER ON
_always 1, 1, 1, 1, 1, 1 1 2147000000 DWORD 2/7
31070
DRIVE_ENC_RATIO_DENOM
- Denominator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31080
DRIVE_ENC_RATIO_NUMERA
- Numerator resolver gearbox (encoder no.) POWER ON
_always 1 1 2147000000 DWORD 2/7
31090
JOG_INCR_WEIGHT
mm, de-
grees
Evaluation of an increment with INC/handwheel RESET
31100
BERO_CYCLE
- Steps for monitoring rotation POWER ON
2000 10 10000000 DWORD 2/7
31110
BERO_EDGE_TOL
- Step tolerance for monitoring rotation POWER ON
50 10 10000000 DWORD 2/7
31350
FREQ_STEP_LIMIT
- Stepping rate at maximum velocity NEW CONF
Hz 250000 0.1 4000000 DOUBLE 2/7
31400
STEP_RESOL
- Steps per stepper motor revolution POWER ON
1000 0 plus DWORD 2/7
31500
AXIS_NUMBER_FOR_MONITORING
- Display setpoint of this axis ollwert for servicing POWER ON
0 0 4 DWORD 2/7
32000
MAX_AX_VELO
mm/min,
rev/min
Maximum axis velocity NEW CONF
_always 10000. 0.0 plus DOUBLE 2/7
