Technical Appendix
6.2 PLC user interface signals
6-141
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Variable for alarm
1600
Variable for alarm [r/w]
Data block
Interface PLC –––––> MMC
Byte
16001000
Variable for alarm 700000
16001004
Variable for alarm 700001
16001008
Variable for alarm 700002
...
16001116
Variable for alarm 700029
16001120
Variable for alarm 700030
16001124
Variable for alarm 700031
Active alarm response
1600
Active alarm response [r]
Data block
Interface PLC –––––> MMC
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Feed
lock
Read–in
disable
NC start
inhibited
16002000 PLC–
STOP
NOT–
AUS
of all axes
16002001
16002002
16002003
