Siemens SINUMERIK 802S User Manual

Start-Up
4.3 Starting up the PLC
4-69
SINUMERIK 802S
6FC5 597–2AA00–0BP2 (01.02)
Table 4-8 Generating the addresses for the V range (see user interface)
Type Code
(DB No.)
Range No.
(Channel/
Axis No.)
Subrange Offset Addressing
00
(00–79)
00
(00–99)
0
(0–9)
000
(000–999)
symbolic
(8–digit)
Table 4-9 S802S Ranges of operands
Accessed by:
Memory Type SINUMERIK 802SC
Bit (Byte.bit) V 14000000.0–79999999.7
I 0.0 – 7.7
Q 0.0 – 7.7
M 0.0 – 127.7
SM 0.0 – 0.6
T 0 – 15
C 0 – 31
L 0.0 – 59.7
Byte VB 14000000–79999999
IB 0 – 7
QB 0 – 7
MB 0 – 127
SMB 0
LB 0 – 59
AC 0 – 3
Word VW 14000000–79999998
IW 0 – 6
QW 0 – 6
MW 0 – 126
T 0 – 15
C 0 – 31
LW 0 – 58
AC 0 – 3
Double Word VD 14000000–79999994
ID 0 – 4
QD 0 – 4
MD 0 – 124
LD 0 – 56
AC 0 – 3
