Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 <_TEXT> STRING
[200]
Text to be engraved (up to 100 characters)
2 RP <_RTP> REAL Retraction plane (abs)
3 Z0 <_RFP> REAL Reference point of tool axis (abs)
4 SC <_SDIS> REAL Safety clearance (to be added to the reference plane, enter without sign)
5 Z1 <_DP> REAL Depth (abs), see <_AMODE>
6 Z1 <_DPR> REAL Depth (inc), see <_AMODE>
7 X0 <_PA> REAL Reference point 1st axis of plane (abs) - right-angled, see <_VARI>
R Reference point, length (radius) - polar, see <_VARI>
8 Y0 <_PO> REAL Reference point 2nd axis of plane (abs) - right-angled, see <_VARI>
α0 Reference point, angle with respect to 1st axis - polar, see <_VARI>
9 α1 <_STA> REAL Text direction, angle of line of text with respect to 1st axis), see <_VARI>
10 XM <_CP1> REAL Center of the text circle, 1st axis of plane (abs) - right-angled,
see <_VARI>
LM Center of circle of text, length (radius) with respect to WNP - polar, see
<_VARI>
11 YM <_CP2> REAL Center of the text circle, 2nd axis of plane (abs) - right-angled, see
<_VARI>
αM Center of text circle, angle with respect to 1st axis axis - polar,
see <_VARI>
12 W <_WID> REAL Height of characters (enter without sign)
13 DX1
DX2
<_DF> REAL Distance between characters / overall width, see <_VARI>
α2 Opening angle, see <_VARI>
14 FZ <_FFD> REAL Depth infeed rate, see <_DMODE>
15 F <_FFP1> REAL Feedrate for surface machining
Work preparation
3.25 Programming cycles externally
NC programming
1042 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
