No. Parameter
mask
Parameter
internal
Data type Meaning
19 <_DMODE> INT Display mode
UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effective before
the cycle call remains active
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Compatibility mode (for recompilation screen
form only), if MD 52216 bit0 = 1
1)
0 = Technology parameters are displayed
(compatibility): TECHNO parameters ef‐
fective
1 = Technology parameters are not dis‐
played: Technology active "as before cy‐
cle call"
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
20 <_AMODE> INT Alternative mode
UNITS: Drilling depth Z1 (abs/inc)
0 = Compatibility, from programming <DP>/
<DPR>
1 = Incremental
2 = Absolute
1)
Technology fields may be hidden, depending on the setting date SD52216 MCS_FUNCTION_MASK_DRILL
2)
Parameters 15, 16 and 17 are only used for thread selection in the screen form thread tables. The thread tables cannot be
accessed via cycle definition in cycle run time.
3.25.1.40 CYCLE899 – open slot
Syntax
CYCLE899(<_RTP>, <_RFP>, <_SDIS>, <_DP>, <_LENG>, <_WID>, <_PA>,
<_PO>, <_STA>, <_MID>, <_MIDA>, <_FAL>, <_FALD>, <_FFP1>, <_CDIR>,
<_VARI>, <_GMODE>, <_DMODE>, <_AMODE>, <_UMODE>, <_FS>, <_ZFS>)
Work preparation
3.25 Programming cycles externally
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1113
