No. Parameter
mask
Parameter
internal
Data type Meaning
20 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Type of feedrate: G group (G94/G95) for
surface and depth feedrate
0 = Compatibility mode
1 = G command as before cycle call.
G94/G95 same for surface and
depth feedrate
21 <_AMODE> INT Alternative mode
UNITS: Final depth (<_DP>, <_DPR>)
0 = Compatibility
1 = Incremental (<_DPR>)
2 = Absolute (<_DP>)
3.25.1.11 CYCLE61 - Face milling
Syntax
CYCLE61(<_RTP>, <_RFP>, <_SDIS>, <_DP>, <_PA>, <_PO>, <_LENG>,
<_WID>, <_MID>, <_MIDA>, <_FALD>, <_FFP1>, <_VARI>, <_LIM>,
<_DMODE>, <_AMODE>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 RP <_RTP> REAL Retraction plane (abs)
2 Z0 <_RFP> REAL Reference point of tool axis, height of blank (abs)
3 SC <_SDIS> REAL Safety clearance (to be added to reference point, enter without sign)
4 Z1 <_DP> REAL Height of finished part (abs/inc), see <_AMODE>
5 X0 <_PA> REAL Corner point 1 in 1st axis (abs)
6 Y0 <_PO> REAL Corner point 1 in 2nd axis (abs)
7 X1 <_LENG> REAL Corner point 2 in 1st axis (abs/inc), see <_AMODE>
8 Y1 <_WID> REAL Corner point 2 in 2nd axis (abs/inc), see <_AMODE>
9 DZ <_MID> REAL Maximum depth infeed
10 DXY <_MIDA> REAL Maximum plane infeed (for unit, see <_AMODE>)
11 UZ <_FALD> REAL Finishing allowance, depth
Work preparation
3.25 Programming cycles externally
NC programming
1044 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
