Page #1259 background imageLoading...
Page #1259 background image
4.3.37 G group 37: Feedrate profile
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
FNORM 1 Feedrate normal to DIN 66025 + m x
FLIN 2 Feed linear variable + m
FCUB 3 Feedrate variable according to cubic spline + m
4.3.38 G group 38: Assignment of fast inputs/outputs for punching/nibbling
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
SPIF1 1 Fast NC inputs/outputs for punching/nibbling byte 1 + m x
SPIF2 2 Fast NC inputs/outputs for punching/nibbling byte 2 + m
4.3.39 G group 39: Programmable contour accuracy
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
CPRECOF 1 Programmable contour accuracy OFF + m x
CPRECON 2 Programmable contour accuracy ON + m
4.3.40 G group 40: Tool radius compensation constant
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
CUTCONOF 1 Constant tool radius compensation OFF + m x
CUTCONON 2 Constant tool radius compensation ON + m
4.3.41 G group 41: Interruptible thread cutting
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
LFOF 1 Interruptible thread cutting OFF + m x
LFON 2 Interruptible thread cutting ON + m
Tables
4.3 G commands
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1259
