Siemens SINUMERIK 804D sl Programming Manual

G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G26 11 Maximum working area limitation/spindle speed limita‐
tion
- s
G110 12 Pole programming relative to the last programmed set‐
point position
- s
G111 13 Polar programming relative to origin of current work‐
piece coordinate system
- s
G112 14 Pole programming relative to the last valid pole - s
G58 15 Absolute programmable work offset - s
G59 16 Additive programmable work offset - s
ROTS 17 Rotation with solid angle - s
AROTS 18 Additive rotation with solid angle - s
4.3.5 G group 4: FIFO
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
STARTFIFO 1 Start FIFO
Execute and simultaneously fill preprocessing memory
+ m x
STOPFIFO 2 STOP FIFO
Stop machining; fill preprocessing memory until
STARTFIFO is detected, FIFO is full or end of program
+ m
FIFOCTRL 3 Activation of automatic preprocessing memory control + m
4.3.6 G group 6: Plane selection
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G17 1 Plane selection 1. – 2. Geometry axis + m x
G18 2 Plane selection 3. – 1. Geometry axis + m
G19 3 Plane selection 2. – 3. Geometry axis + m
4.3.7 G group 7: Tool radius compensation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
G40 1 No tool radius compensation + m x
G41 2 Tool radius compensation left of the contour - m
G42 3 Tool radius compensation right of the contour - m
Tables
4.3 G commands
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1249
