Page #1046 background image
No. Parameter
mask
Parameter
internal
Data type Meaning
16 <_AMODE> INT Alternative mode
UNITS: Final depth (<_DP>)
0 = Absolute
1 = Incremental
TENS: Units for plane infeed (<_MIDA>)
0 = mm
1 = % of tool diameter
HUNDREDS: Reserved
THOUSANDS: Length of surface
0 = Incremental
1 = Absolute
TEN THOUSANDS: Width of surface
0 = Incremental
1 = Absolute
3.25.1.12 CYCLE62 - contour call
Syntax
CYCLE62(<_KNAME>,<_TYPE>, <_LAB1>, <_LAB2>)
Parameters
No. Parameter
mask
Parameter
internal
Data type Meaning
1 PRG/CON <_KNAME> STRING
[140]
Contour name or subprogram name does not have to be programmed
in _TYPE = 2
2 <_TYPE> INT Determination of contour input
0 = Subprogram
1 = Contour name
2 = Labels
3 = Labels in the subprogram
3 LAB1 <_LAB1> STRING[32] Label 1, start of contour
4 LAB2 <_LAB2> STRING[32] Label 2, end of contour
3.25.1.13 CYCLE63 – contour pocket milling / contour pocket residual material / contour spigot
milling / contour spigot residual material
Syntax
CYCLE63(<_PRG>, <_VARI>, <_RP>, <_Z0>, <_SC>, <_Z1>, <_F>, <_FZ>,
<_DXY>, <_DZ>, <_UXY>, <_UZ>, <_CDIR>, <_XS>, <_YS>, <_ER>, <_EP>,
Work preparation
3.25 Programming cycles externally
NC programming
1046 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
