4.3.33 G group 33: Settable fine tool offset
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
FTOCOF 1 Online fine tool offset OFF + m x
FTOCON 2 Online fine tool offset ON - m
4.3.34 G group 34: Tool orientation smoothing
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
OSOF 1 Tool orientation smoothing OFF + m x
OSC 2 Continuous tool orientation smoothing + m
OSS 3 Tool orientation smoothing at end of block + m
OSSE 4 Tool orientation smoothing at start and end of block + m
OSD 5 Block-internal smoothing with specification of path
length
+ m
OST 6 Block-internal smoothing with specification of angular
tolerance
+ m
4.3.35 G group 35: Punching and nibbling
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
SPOF 1 Stroke US, punching and nibbling OFF + m x
SON 2 Nibbling ON + m
PON 3 Punching ON + m
SONS 4 Nibbling ON in interpolation cycle - m
PONS 5 Punching ON in interpolation cycle - m
4.3.36 G group 36: Punching with delay
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
PDELAYON 1 Punching with delay ON + m x
PDELAYOF 2 Punching with delay OFF + m
Tables
4.3 G commands
NC programming
1258 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
