No. Parameter Data type Meaning
8 <S_A1> AXIS Infeed axis (optional) or 1st geometry axis
9 <S_A2> AXIS Oscillating axis (optional) or 2nd geometry axis
Function
The cycle is used for the execution of repeating infeeds taking into account e.g. an external
cancel signal. The infeed depth can be different at the start and at the end. The depth infeed is
cancelled when the cancel condition is satisfied. A complete stroke is always performed after
the cancellation of the depth infeed.
Sequence
Cancellation of the infeed from the end to the start







6B$!
6B%!
6B:!
) 6B.!
6B8!
6B8!
6B*$8*(!
6B8!
Work preparation
3.25 Programming cycles externally
NC programming
1138 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
