Siemens SINUMERIK 804D sl Programming Manual

Transverse axis
Generally the dimensions for the transverse axis are diameter specifications (double path
dimension compared to other axes):
/RQJLWXGLQDOD[LV
7UDQVYHUVHD[LV
'
:
'
0
=
;
The geometry axis that is to serve as transverse axis is defined in the machine data (→ machine
manufacturer).
Fundamentals
2.8 Geometry settings
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 169
