Function of the system variables for orientable toolholders
α
1
angle of rota‐
tion
α
2
angle of rota‐
tion
$TC_CARR13[m]
$TC_CARR14[m]
l
3
offset vector $TC_CARR15[m] $TC_CARR16[m] $TC_CARR17[m]
Extensions of the system variables for orientable toolholders
Designation x component y component z component
l
4
offset vector $TC_CARR18[m] $TC_CARR19[m] $TC_CARR20[m]
Axis identifier Ro‐
tary axis v
1
Rotary axis v
2
Axis identifier of the rotary axes v
1
and v
2
(initialized with zero)
$TC_CARR21[m]
$TC_CARR22[m]
Kinematic type
Tool
Part
Mixed mode
$TC_CARR23[m]
Kinematics type T -> Kinematics type P -> Kinematics type M
Only the tool can rotate
(default).
Only the part can rotate Part and tool can rotate
Offset of the
Rotary axis v
1
Rotary axis v
2
Angle in degrees of the rotary axes v
1
and v
2
on assuming the initial setting
$TC_CARR24[m]
$TC_CARR25[m]
Angle offset of
the rotary axis v
1
Rotary axis v
2
Offset of the Hirth tooth system in degrees for rotary axes v
1
and v
2
$TC_CARR26[m]
$TC_CARR27[m]
Angle increment
v
1
rotary axis
v
2
rotary axis
Offset of the Hirth tooth system in degrees for rotary axes v
1
and v
2
$TC_CARR28[m]
$TC_CARR29[m]
Min. position Ro‐
tary axis v
1
Rotary axis v
2
Software limit for the minimum position of the rotary axes v
1
and v
2
$TC_CARR30[m]
$TC_CARR31[m]
Max. position Ro‐
tary axis v
1
Rotary axis v
2
Software limits for the maximum position of the rotary axes v
1
and v
2
$TC_CARR32[m]
$TC_CARR33[m]
Toolholder name A toolholder can be given a name instead of a number. $TC_CARR34[m]
User:
Axis name 1
Axis name 2
Identifier
Position
Intended use in user measuring cycles $TC_CARR35[m]
$TC_CARR36[m]
$TC_CARR37[m]
$TC_CARR38[m] $TC_CARR39[m] $TC_CARR40[m]
Fine
offset
Parameters that can be added to the values
in the basic parameters.
l
1
offset vector $TC_CARR41[m] $TC_CARR42[m] $TC_CARR43[m]
l
2
offset vector $TC_CARR44[m] $TC_CARR45[m] $TC_CARR46[m]
l
3
offset vector $TC_CARR55[m] $TC_CARR56[m] $TC_CARR57[m]
l
4
offset vector $TC_CARR58[m] $TC_CARR59[m] $TC_CARR60[m]
v
1
rotary axis $TC_CARR64[m]
v
2
rotary axis $TC_CARR65[m]
Work preparation
3.13 Tool offsets
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 779
