Siemens SINUMERIK 804D sl Programming Manual

ROT Z60
The direction of the applicate (Z direction) remains unchanged; the main component of L2 now
lies in the direction of the new X axis; the main component of L1 now lies in the direction of the
negative Y axis. As a consequence, the return value (<Status>) is "1", <AxInd> contains the
values (2, -3, 1).
In this case, the associated matrix (<Matrix>) is:
0DWUL[! 




FRVr
VLQr

VLQr
FRVr
Work preparation
3.13 Tool offsets
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 833
