Siemens SINUMERIK 804D sl Programming Manual

LL
F
F
Definition range
Master
value
Slave value
CTAB with periodic curve tables
If the specified <master value> is outside the definition range, the master value is evaluated
modulo of the definition range and the corresponding following value is output:
L
F
Definition range
Master
value
Slave value
Approximate value for CTABINV
The CTABINV command, therefore, requires an approximate value for the expected master
value. CTABINV returns the leading value that is closest to the approximate value. The
approximate value can be, for example, the master value from the previous interpolator clock
cycle.
Work preparation
3.16 Axis couplings
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 909
