Technical specifications
11.4 Technical specifications of analyzer modules
128
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
General
ULTRAMAT 7
ULTRAMAT 7 high-temperature
Electrical safety In accordance with
DIN EN 61010-1
Max. EMC error during opera-
tion with one and/or two
OXYMAT 7/ ULTRAMAT 7 units
1.0% according to EN 61326-1 (2013)
Table 11- 23 ULTRAMAT 7: Measuring ranges
Measuring ranges
Number of measuring ranges
Max. 4; parameters can be assigned freely
Component that
can have pa-
rameters as-
signed in the
measuring
ranges
Component
Smallest possible span
Largest possible span
CO
0 ... 10 ppm
0 ... 100%
CO
2
0 ... 5 ppm
0 ... 100%
CH
4
0 ... 50 ppm
0 ... 100%
C
2
H
4
0 … 300 ppm
0 ... 100%
SO
2
0 ... 50 ppm
0 ... 100%
NO
0 … 100 ppm
0 ... 3%
N
2
O
0 ... 50 ppm
0 ... 100%
NH
3
0 … 100 ppm
0 ... 100%
CO/NO
0 ... 100 ppm
0 ... 10000 ppm
CO/NO
(combination
with O7)
CO 0 ... 100/NO 0 ... 300 ppm CO 0 ... 3000 ppm/NO
0 ... 3000 ppm
CO
2
/CO
0 ... 100 ppm
0 ... 100%
Table 11- 24 ULTRAMAT 7: Gas inlet conditions
Gas inlet conditions
Sample gas
pressure
Normal pressure (atmospheric
pressure compensation)
500 to 1 500 hPa (absolute)
Pressure loss between sample gas inlet and sample
gas outlet
< 10 hPa at 1.5 l/min
Sample gas flow 18 to 90 l/h (0.3 to 1.5 l/min)
1)
Sample gas temperature and humidity
ULTRAMAT 7 standard version 0 ... 50 °C at relative humidity < 90%, in rela-
tion to the respective ambient temperature;
avoid condensation in gas path (moisture con-
tent results in measurement errors)
ULTRAMAT 7 high-temperature 0 ... 65 °C at relative humidity < 90%, in refer-
ence to the respective ambient temperature;
avoid condensation in gas path (moisture con-
tent results in measurement errors)
1)
Nominal values in the section "Determining the technical specifications"
