Siemens SIPROCESS GA700 - Calomat 7

Connecting
6.1 Gas connections
48
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
6.1.4.3
CALOMAT 7
Arrangement of the gas connections in the rack-mounted device
①
Slot of analyzer module 1: CALOMAT 7
②
Slot of analyzer module 2
1
Sample gas inlet
2
Sample gas outlet
3
Not assigned
4
Not assigned
Figure 6-6 CALOMAT 7 gas connections in the rack unit, rear
