Design of the gas connections
Dimensions of purging gas couplings
Length Without sealing caps 28 mm
1. Connect the gas lines by means of suitable clamping screws to the associated gas inlets
and outlets.
When tightening the union nuts at the screwed connections, make sure that you counter
properly with a suitable open-ended spanner.
2. Check that the clamping screws are secure and that the pipe connections are tight.
Electrical connections
6.2.1
General safety instructions for electrical connections
Incorrect electrical connection
Danger of electrocution
• Connect the device to the power supply in accordance with the technical specifications.
The information about proper electrical connection is available in section "Technical
specifications (Page 119)".
• At the mounting location of the device observe the applicable directives and laws for
installation of electrical power installations with rated voltages below 1000 V.
