Siemens SIPROCESS GA700 Quick Start

Technical specifications
11.4 Technical specifications of analyzer modules
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
133
Influence variables
Accompanying gases (interference
gases)
The interference gas sensitivity depends on the application
and must be determined in each case except for applica-
tions with blast furnace gas / converter gas / wood gasifica-
tion (pre-adjusted).
Supply voltage
(fluctuations of the power supply of the
basic device
2)
in the range of
85 V AC to 264 V AC / 47 Hz to 63 Hz)
≤ ± 0.1% of full-scale value
1)
Values less than the detection limit are not useful
2)
Basic device: 7MB3000-0xxx0-1xx0 rack-/wall-mounted enclosure
Table 11- 40 CALOMAT 7: Climatic conditions
Climatic conditions
Storage and transport
-30 to +70 °C
Max. permissible ambient temperature
surrounding the basic device during
operation
1)
0 to 50 °C
Ambient humidity (relative humidity)
during storage, transport or operation
2)
< 90%
1)
Restriction for installing an ULTRAMAT 7 analyzer module: 5 to 45 °C
2)
Avoid condensation on the installed components!
Table 11- 41 CALOMAT 7: Gas connections
Gas connections
Connection fittings
Pipe diameter 6 mm (outer diameter)
Table 11- 42 CALOMAT 7: Parts in contact with sample gases
Materials of wetted parts
Gas connection
Stainless steel (Material No. 1.4571)
Clamping rings and union nut (set) Stainless steel (Material No. 1.4401)
Sample gas pipes Stainless steel (Material No. 1.4404)
Sensor mounting block Stainless steel (Material No. 1.4571)
Sensor
Si, SiO
x
N
y
, Au, epoxy resin, glass
Gasket, contained in the sensor mod-
ule
Perfluorelastomere FFPM
