Siemens SIPROCESS GA700 Quick Start

Combination operation
4.3 Gas connections
24
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
CALOMAT 7
Table 4- 3 Mounting position for the sample gas restrictor: CALOMAT 7
Operating mode
Clamping screw
Operation with one or two CALOMAT 7
Pressure operation/Suction operation Pre-assembled clamping screws. No retrofitting or disman-
tling.
OXYMAT 7 / ULTRAMAT 7 / CALOMAT 7
Table 4- 4 Mounting position for the sample gas restrictor
Operating
mode
Sample gas restrictor/clamping screw
OXYMAT 7 /
ULTRAMAT 7
ULTRAMAT 7 / CALOMAT 7
OXYMAT 7 / CALOMAT 7
Pressure
operation
OXYMAT 7 must always
be purged first.
Install a sample gas
restrictor in front of the
sample gas inlet of the
OXYMAT 7.
We recommend purging the
CALOMAT 7 as the first
module
No restrictions
Suction ope-
ration
ULTRAMAT 7 must
always be purged first.
Install a sample gas
restrictor in the sample
gas outlet of the
OXYMAT 7.
Replace a sample gas
restrictor in the sample
gas inlet of the
OXYMAT 7 with a clamp-
ing screw.
