Siemens SIPROCESS GA700 Quick Start

Commissioning
7.7 Commissioning the device
90
Quick Start
Compact Operating Instructions, 05/2018, A5E31805656-06
Setting analog output ranges
1. Call up submenu "04 Analog outputs":
Main menu > "1. Quick Start" > "04 Analog outputs"
The menu includes one navigation line for each of the five analog output ranges that can
be set:
Structure of the navigation line for each analog output range
Component name Analog output range
2. Set the output current range of an analog output:
– Open the parameter field you wish to edit: Press <ENTER>.
– Authorize access with Standard PIN, if necessary.
– Set the analog output range according to the table below:
Specified analog output
range [mA]
Measuring range limit
Normal operation [mA]
Fault/CTRL
1)
[mA]
Low limit
High limit
Low limit
High limit
4 to 20 (NAMUR)
3.8
20.5
3
21.5
4 ... 20
2
21
2
21
0 ... 20
0
21
0
21
20 to 0
2)
0
21
0
21
20 to 4
2)
2
21
2
21
1)
CTRL = Function check
2)
Inversion
3. Repeat step 2 for all additional analog output current ranges.
