1 Reference gas inlet
2 Reference gas outlet
3 Sample gas outlet
4 Sample gas inlet
Test setup for leakage test with ULTRAMAT 7 high-temperature
To check for leaks, we recommend the following test setup:
Commissioning
5.4Checking gas paths for leaks
SIPROCESS GA700 rack and wall mounted devices
Compact Operating Instructions, 06/2023, A5E35134047-AB 73
