Siemens SIPROCESS GA700 Compact Operating Instructions

Technical data
7
7.1 General technical speci󹪝cations
Note
Minimum wait time before opening is 10 minutes.
7.1.1 Rack-mounted housing
Table 7-1 Rack-mounted housing: General technical data
General
Installation position Horizontal
Weight Approx. 8.5kg
Degree of protection IP20 according to EN / IEC60529
Electrical characteristics
Auxiliary power supply 100to240VAC (nominal range of use 85to264V)
50to60Hz (nominal range of use 47to63Hz)
Power consumption Max. 280VA
EMC interference im‐
munity (electromag‐
netic compatibility)
during operation:
with one and/or two OXY‐
MAT 7 / ULTRAMAT7 units
in accordance with the standard requirements of NA‐
MURNE21(05/2006) and EN / IEC61326-1
with one or two CALOMAT 7
units
in accordance with standard requirements EN61326-1
Electrical safety in accordance with EN / IEC61010-1, overvoltage category II and in‐
stallation category II
Equipotential bonding on housing 4 mm² (11 AWG) (For installation in Ex areas)
Transient protection if the type of protection Ex e is
used
It has to be ensured that the transient protection is set to a value 500
V for 230 V mains power and 260 V for 120 V mains power. Ensure that
voltages above 544 V can never occur.
Power unit cable
• Cable diameter: max. Ø10mm (0.39″)
• Core cross-section: max. 3 x 2.1 mm
2
(3 x 14 AWG) min. 3 x 0.75
mm² (3 x 18 AWG)
Ensure that the cross section of PE is always equal or greater than the
cross section of line and neutral.
SIPROCESS GA700 rack and wall mounted devices
Compact Operating Instructions, 06/2023, A5E35134047-AB 87
