5.4.1.2 Recommended test setup for the OXYMAT 7 high-temperature
Arrangement of gas connections in the OXYMAT 7 high-temperature in the wall-mounted device
The following 󹪝gure shows the gas connections of a high-temperature OXYMAT 7:


1 Reference gas inlet
2 Sample gas inlet
3 Sample gas inlet
Test setup for leakage test with OXYMAT 7 high-temperature
To check for leaks, we recommend the following test setup:
Commissioning
5.4Checking gas paths for leaks
SIPROCESS GA700 rack and wall mounted devices
Compact Operating Instructions, 06/2023, A5E35134047-AB 71
