5.4.2.3 Checking CALOMAT 7 for leaks
Procedure
1. Connect a pressure measuring instrument (manometer) to the sample gas outlet.
Measuring range approx. 200hPa rel. to 1000hPa rel. with appropriate measured value
resolution (0.1hPa).
Absolute pressure gauges with correspondingly good resolution are also suitable.
2. Connect the sample gas inlet to a compressed air source via a shuto󹪜 mechanism. The valves
in use must provide a leakage rate <10
-4
hPa*l/s.
3. Pressurize the analyzer module step-by-step with an overpressure of 400hPa.
4. Close the shuto󹪜 mechanism and wait for 5 minutes until the sample gas that 󹪞owed in has
reached the ambient temperature.
5. Note the pressure.
6. Wait 5 minutes. Note the pressure again.
If the pressure change lies under 5hPa, the sample gas path is adequately tight.
This value is based on the tare volume of the measuring module 6 ml and the volume of the
pressure measuring device of 23 ml.
5.5 Local commissioning
WARNING
Commissioning and operation with error message
If an error message displays, correct operation is no longer guaranteed.
• Check the severity of the error.
• Correct the error.
• If the error still exists:
– Take the device out of operation.
– Do not restart the device.
The same risk continues to apply when error messages are switched o󹪜 or disabled.
Commissioning
5.5Local commissioning
SIPROCESS GA700 rack and wall mounted devices
Compact Operating Instructions, 06/2023, A5E35134047-AB 77
