Electrical inputs and outputs
Digital outputs (DO) 8, with changeover contacts, parameters can be freely assigned, e.g. for measuring range
identi󹪝cation; max. load: 24 V AC/DC/1.7 A (total load for all 8 relay outputs in continuous
operation max. 160W), isolated, non-sparking
Digital inputs (DI) 8, designed for 24V, isolated, freely parameterizable, e.g. for autoranging
Ethernet interface (rear) Ethernet RJ 45, 100 Mbps
Table 7-2 Rack-mounted housing: Option modules
Option modules
Option module 1.1
• 12 digital outputs, with changeover contacts, max. load: 24V AC/DC / 1.7A
(total load for all 12 relay outputs in continuous operation max. 244 W), isolated, non-
sparking
• 8 digital inputs, designed for 24V, isolated, freely con󹪝gurable
Option module 2.1
• 6 analog outputs 0/4...20mA, designed for 24 V, isolated; load: R
L
≤750Ω
• 6 digital outputs, load rating: 24VAC/DC/1.7A(total load for all 6 relay outputs in
continuous operation max. 122W), isolated, non-sparking
Option module 2.2 I/O
• 6 analog outputs 0/4to20mA, designed for 24V, isolated; max. load 750Ω
• 4 analog inputs 0/4to20mA, designed for 24V, non-isolated, internal resistance
100Ω
• 4 digital inputs, designed for 24V, isolated
Option module 2.2 Pro󹪝bus DP
• no additional inputs and outputs
• Pro󹪝bus communication
Table 7-3 Rack-mounted housing: Climatic conditions
Climatic conditions
Permissible operating altitude 3000m above sea level sea level
Permissible ambient temperature
for OXYMAT 7 and CALOMAT 7
1)
0 ... 50 °C (32 ... 122 °F)
Permissible ambient temperature
during operation for ULTRAMAT 7
5 °C ... +45 °C (41 ... +133 °F)
Storage and transport - 30 … +70 °C (-22 ... 158 °F)
Ambient humidity (relative humid‐
ity) during storage, transport or op‐
eration
< 90%
No cooling below dew point during storage and operation
Pollution degree 2
1.) Reduction of permissible temperature range in case of operation in combination with Ultramat 7.
Technical data
7.1General technical speci󹪝cations
SIPROCESS GA700 rack and wall mounted devices
88 Compact Operating Instructions, 06/2023, A5E35134047-AB
