Siemens SIPROCESS GA700 Compact Operating Instructions

Table 7-26 CALOMAT 7: Gas inlet conditions
Gas inlet conditions
Sample gas pressure -300 to +400 hPa
Pressure drop between sample gas inlet and out‐
let
<50hPa at 1.5l/min
Sample gas 󹪞ow 30to90l/h (0.5to1.5l/min)
Sample gas temperature and humidity 0 … 70 °C (32 ... 158 °F) with relative humidity < 90%, avoid condensation
in the gas path (moisture content results in measurement errors)
Table 7-27 CALOMAT 7: Temperature of sample chamber and gas path
Temperature of sample chamber and gas path
Gas path 5K above ambient temperature
All versions 72°C (162°F)
Table 7-28 CALOMAT 7: Climatic conditions
Climatic conditions
Storage and transport -30…+70°C (-22 ... 158 °F)
Max. permissible ambient temperature surround‐
ing the basic device during operation
1)
0…50°C (32 ... 122 °F)
Ambient humidity (relative humidity) during stor‐
age, transport or operation
2)
<90%
1)
Restriction for installing an ULTRAMAT7 analyzer module (combined operation): 5…45°C (41 ... 113 °F)
2)
Avoid condensation on the installed components
Table 7-29 CALOMAT 7: Gas connections
Gas connections
Connection 󹪝ttings Pipe diameter: Ø 6mm (0.23") (outer diameter)
Table 7-30 CALOMAT 7: Parts in contact with sample gases
Materials of wetted parts
Gas connection Stainless steel (Material No. 1.4571)
Clamping rings and union nut (set) Stainless steel (Material No. 1.4401)
Sample gas pipes Stainless steel (Material No. 1.4404)
Sensor mounting block Stainless steel (Material No. 1.4571)
Sensor Si, SiO
x
N
y
, Au, epoxy resin, glass
Gasket, contained in the sensor module Per󹪞uorelastomere FFPM
Technical data
7.1General technical speci󹪝cations
SIPROCESS GA700 rack and wall mounted devices
Compact Operating Instructions, 06/2023, A5E35134047-AB 97
