Siemens SIPROTEC4 7UM62 - Coil Status Registers (0 X References); Registers 00001 to 00010: Internal Commands; Registers 00011 to 00026: Single Commands and Taggings

Standard mapping 3-1
2-2
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.1 Coil Status registers (0X references)
2.1.1 Registers 00001 to 00010: Internal Commands
• Ref. to chap. 1.3.1 for additional notes regarding “Changing the setting group”.
2.1.2 Registers 00011 to 00026: Single commands and taggings
• User-defined single commands and taggings can be routed on these positions as
“Source/Destination system interface” using the DIGSI Configuration
matrix.
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00001
Command: Setting Group A
0 = not permitted
1 = Activation of setting group A
53
Indication: Setting Group A
0 = Setting group A is not active
1 = Setting group A is active
00002
Command: Setting Group B
0 = not permitted
1 = Activation of setting group B
54
Indication: Setting Group B
0 = Setting group B is not active
1 = Setting group B is active
00003
-
00010
reseved
The value 0 is always returned if reading.
A write access is rejected in the SIPROTEC device.
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00011 <user-defined> not pre-allocated -
00012 <user-defined> not pre-allocated -
00013 <user-defined> not pre-allocated -
00014 <user-defined> not pre-allocated -
00015 <user-defined> not pre-allocated -
00016 <user-defined> not pre-allocated -
00017 <user-defined> not pre-allocated -
00018 <user-defined> not pre-allocated -
00019 <user-defined> not pre-allocated -
00020 <user-defined> not pre-allocated -
00021 <user-defined> not pre-allocated -
00022 <user-defined> not pre-allocated -
00023 <user-defined> not pre-allocated -
00024 <user-defined> not pre-allocated -
00025 <user-defined> not pre-allocated -
00026 <user-defined> not pre-allocated -
