Siemens SIPROTEC4 7UM62 - Registers 10051 to 10058: Frequency Protection; Registers 10059 to 10063: Overexcitation Protection; Registers 10064 to 10066: Reverse Power Protection; Registers 10067 to 10070: Forward Power Supervision

Standard mapping 3-2
3-7
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
3.2.12 Registers 10051 to 10058: Frequency protection
3.2.13 Registers 10059 to 10063: Overexcitation protection
3.2.14 Registers 10064 to 10066: Reverse power protection
3.2.15 Registers 10067 to 10070: Forward power supervision
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10051 81-1 picked up 1 = 81-1 picked up 5232
10052 81-2 picked up 1 = 81-2 picked up 5233
10053 81-3 picked up 1 = 81-3 picked up 5234
10054 81-4 picked up 1 = 81-4 picked up 5235
10055 81-1 TRIP 1 = 81-1 TRIP 5236
10056 81-2 TRIP 1 = 81-2 TRIP 5237
10057 81-3 TRIP 1 = 81-3 TRIP 5238
10058 81-4 TRIP 1 = 81-4 TRIP 5239
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10059 24 warn 1 = 24 V/f warning stage 5367
10060 24-1 picked up 1 = 24-1 V/f> picked up 5370
10061 24-2 picked up 1 = 24-2 V/f>> picked up 5373
10062 24 th.TRIP 1 = 24 TRIP of thermal stage 5372
10063 24-2 TRIP 1 = 24-2 TRIP of V/f>> stage 5371
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10064 32R picked up 1 = 32R picked up 5096
10065 32R TRIP 1 = 32R TRIP 5097
10066 32R+SV TRIP 1 = 32R TRIP with stop valve 5098
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10067 32F< picked up 1 = 32F P< stage picked up 5126
10068 32F> picked up 1 = 32F P> stage picked up 5127
10069 32F P< TRIP 1 = 32F P< stage TRIP 5128
10070 32F P> TRIP 1 = 32F P> stage TRIP 5129
