Siemens SIPROTEC4 7UM62 - Register 10071: Fuse Failure Monitor; Registers 10072 to 10077: Underexcitation Protection; Registers 10078 to 10079: Circuit Breaker Failure Protection; Registers 10080 to 10087: Impedance Protection

Standard mapping 3-1
2-8
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.2.16 Register 10071: Fuse Failure Monitor
2.2.17 Registers 10072 to 10077: Underexcitation protection
2.2.18 Registers 10078 to 10079: Circuit breaker failure protection
2.2.19 Registers 10080 to 10087: Impedance protection
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10071 VT Fuse Failure 1 = Voltage Transformer Fuse Failure 6575
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10072 40 Vexc failure 1 = 40 Exc. voltage failure recognized 5336
10073 40 picked up 1 = 40 picked up 5337
10074 40-1 TRIP 1 = 40 characteristic 1 TRIP 5344
10075 40-2 TRIP 1 = 40 characteristic 2 TRIP 5345
10076 40&V<TRIP 1 = 40 characteristic&Vexc< TRIP 5346
10077 40-3 TRIP 1 = 40 characteristic 3 TRIP 5343
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10078 50BF pickup 1 = 50BF picked up 1455
10079 50BF TRIP 1 = 50BF TRIP 1471
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10080 21 Fault Ph A 1 = 21 Fault detection , Phase A 3967
10081 21 Fault Ph B 1 = 21 Fault detection , Phase B 3968
10082 21 Fault Ph C 1 = 21 Fault detection , Phase C 3969
10083 21 I> & U< 1 = 21 O/C with undervoltage seal in 3970
10084 21 Z1< TRIP 1 = 21 Z1< TRIP 3977
10085 21 Z1B< TRIP 1 = 21 Z1B< TRIP 3978
10086 21 Z2< TRIP 1 = 21 Z2< TRIP 3979
10087 21 T3> TRIP 1 = 21 T3> TRIP 3980
