Siemens SIPROTEC4 7UM62 - Registers 40351 to 40410: MinMax Values of Measured Values

Standard mapping 3-2
3-17
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
3.4.7 Registers 40351 to 40410: Min/Max values of measured values
• Registers are write-protected.
1
• Min/Max values of measured values can be routed on these register positions using
the DIGIS Configuration matrix.
• The transmission of Min/Max values of measured values is only possible as primary
values.
• Information regarding the Time/Date data type you find in the manual “SIPROTEC
Communication module, Modbus - Communication profile” (ref to page i).
• Registers 40351 to 40410 are available with 7UM62 V4.10 or higher.
1. A write access is rejected with exception code 03 (ILLEGAL_DATA_VALUE).
Register
Designation of the
SIPROTEC objects
Comments
Scaling
(32767 corre-
sponds to ...)
Internal
object no.
40351 <user-defined> Min/Max not pre-allocated
--
40352
_
40355
Time/Date Time and Date of “<user-defined> Min/Max”
40356 <user-defined> Min/Max not pre-allocated
--
40357
_
40360
Time/Date Time and Date of “<user-defined> Min/Max”
40361 <user-defined> Min/Max not pre-allocated
--
40362
_
40365
Time/Date Time and Date of “<user-defined> Min/Max”
40366 <user-defined> Min/Max not pre-allocated
--
40367
_
40370
Time/Date Time and Date of “<user-defined> Min/Max”
40371 <user-defined> Min/Max not pre-allocated
--
40372
_
40375
Time/Date Time and Date of “<user-defined> Min/Max”
40376 <user-defined> Min/Max not pre-allocated
--
40377
_
40380
Time/Date Time and Date of “<user-defined> Min/Max”
40381 <user-defined> Min/Max not pre-allocated
--
40382
_
40385
Time/Date Time and Date of “<user-defined> Min/Max”
40386 <user-defined> Min/Max not pre-allocated
--
40387
_
40390
Time/Date Time and Date of “<user-defined> Min/Max”
