SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
3.1.3 Registers 00027 to 00030: Double commands
• User-defined double commands and associated checkback indications as double-
point indications can be routed on these positions as “Source/Destination system
interface” using the DIGSI Configuration matrix.
• Please ref. to chap. “Double command / Double-point indication” in the manual
“SIPROTEC Communication module, Modbus - Communication profile” for addi-
tional notes.
• Registers 00027 to 00030 are available with 7UM62 V4.10 or higher.
3.1.4 Registers 00257 to 00264: Exception Flags
• Registers are write-protected.
1
• The contents of these registers are also readable using function "Read Exception
Status" (function code 7).
• Installation-specific SIPROTEC objects can be routed on these register positions
using parameterization system DIGSI.
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00027 <user-defined> ON
not pre-allocated -
00028 <user-defined> OFF
00029 <user-defined> ON
not pre-allocated -
00030 <user-defined> OFF
1. A write access is rejected with exception code 03 (ILLEGAL_DATA_VALUE).
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
00257 <user-defined> not pre-allocated -
00258 <user-defined> not pre-allocated -
00259 <user-defined> not pre-allocated -
00260 <user-defined> not pre-allocated -
00261 <user-defined> not pre-allocated -
00262 <user-defined> not pre-allocated -
00263 <user-defined> not pre-allocated -
00264 <user-defined> not pre-allocated -
