Siemens SIPROTEC4 7UM62 - Registers 10037 to 10040: Stator Ground Fault Protection; Registers 10041 to 10042: Stator Ground Fault Protection with 3; Registers 10043 to 10046: Overvoltage Protection; Registers 10047 to 10050: Undervoltage Protection

Standard mapping 3-1
2-6
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.2.8 Registers 10037 to 10040: Stator ground fault protection
2.2.9 Registers 10041 to 10042: Stator ground fault protection with 3
rd
harmonic
2.2.10 Registers 10043 to 10046: Overvoltage protection
2.2.11 Registers 10047 to 10050: Undervoltage protection
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10037 59/67 V0 PU 1 = 59N/67GN V0 picked up 5186
10038 59/67 I0 PU 1 = 59N/67GN I0 picked up 5188
10039 59/67 V0 TRIP 1 = 59N/67GN V0 stage TRIP 5187
10040 59N/67GN TRIP 1 = 59N/67GN TRIP 5193
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10041 27TN/59TN PU 1 = 27TN/59TN with 3
rd
harmomic picked up 5567
10042 27TN/59TN TRP 1 = 27TN/59TN with 3
rd
harmomic TRIP 5568
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10043 59-1 picked up 1 = 59-1 Overvoltage V> picked up 6568
10044 59-2 picked up 1 = 59-2 Overvoltage V>> picked up 6571
10045 59-1 TRIP 1 = 59-1 Overvoltage V> TRIP 6570
10046 59-2 TRIP 1 = 59-2 Overvoltage V>> TRIP 6573
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10047 27-1 picked up 1 = 27-1 Undervoltage V< picked up 6533
10048 27-2 picked up 1 = 27-2 Undervoltage V<< picked up 6537
10049 27-1 TRIP 1 = 27-1 Undervoltage V< TRIP 6539
10050 27-2 TRIP 1 = 27-2 Undervoltage V<< TRIP 6540
