2.2.25 Register 10100: Startup counter for motors
2.2.26 Registers 10101 to 10102: Rotor ground fault protection (R,fn)
2.2.27 Registers 10103 to 10104: DC voltage/current protection
2.2.28 Registers 10105 to 10108: State of the out-of-step protection
2.2.29 Registers 10109 to 10115: Differential protection
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10100 66 TRIP 1 = 66 Restart inhibit motor TRIP 4827
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10101 64R-1 picked up 1 = 64R-1 picked up (Alarm) 5397
10102 64R-2 TRIP 1 = 64R-2 TRIP 5399
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10103 DC Prot.pick.up 1 = DC protection picked up 5306
10104 DC Prot. TRIP 1 = DC protection TRIP 5307
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10105 78 det. char. 1 1 = 78 characteristic 1 picked up 5069
10106 78 det. char. 2 1 = 78 characteristic 2 picked up 5070
10107 78 TRIP char. 1 1 = 78 TRIP characteristic 1 5071
10108 78 TRIP char. 2 1 = 78 TRIP characteristic 2 5072
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10109 87 picked up 1 = 87 Differential protection picked up 5631
10110 87 TRIP 1 = 87 Differential protection TRIP 5671
10111 87 TRIP Phase A 1 = 87 Differential protection: TRIP Phase A 5672
10112 87 TRIP Phase B 1 = 87 Differential protection: TRIP Phase B 5673
10113 87 TRIP Phase C 1 = 87 Differential protection: TRIP Phase C 5674
10114 87 Diff> TRIP 1 = 87 Differential prot.: TRIP by IDIFF> 5691
10115 87 Diff>> TRIP 1 = 87 Diff>> TRIP 5692
