Siemens SIPROTEC4 7UM62 - Input Registers (3 X References)

Standard mapping 3-1
2-12
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.3 Input registers (3X references)
• Ref. to chap. 1.2.3 for additional notes regarding scaling of measured values.
Register
Designation of the
SIPROTEC objects
Comments
Scaling
(32767 corresponds to ...)
Internal
object no.
30001 IA S2= Operat. meas. current A side 2 327.67 % 724
30002 IB S2= Operat. meas. current B side 2 327.67 % 725
30003 IC S2= Operat. meas. current C side 2 327.67 % 726
30004 Va-b= Va-b 327.67 % 624
30005 Vb-c= Vb-c 327.67 % 625
30006 Vc-a= Vc-a 327.67 % 626
30007 P = P (active power) 327.67 % 641
30008 Q = Q (reactive power) 327.67 % 642
30009 f = Frequency 327.67 Hz 644
30010 I2 = I2 (negative sequence) 327.67 % 606
30011 Θ/Θtrip = Temperature rise for warning and trip 327.67 % 801
30012 <user-defined> not pre-allocated - -
30013 IA S1= Operat. meas. current A side 1 327.67 % 721
30014 IB S1= Operat. meas. current B side 1 327.67 % 722
30015 IC S1= Operat. meas. current C side 1 327.67 % 723
