SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.2.30 Registers 10116 to 10117: Stator ground fault protection 100%
• Registers 10116 and 10117 are available with 7UM62 V4.10 or higher.
2.2.31 Registers 10118 to 10119: Rotor ground fault protection 1-3 Hz
• Registers 10118 and 10119 are available with 7UM62 V4.10 or higher.
2.2.32 Registers 10120 to 10121: Restricted ground fault protection
• Registers 10120 and 10121 are available with 7UM62 V4.10 or higher.
2.2.33 Registers 10122 to 10129: Fault indications of protection functions
• User-defined protection annunciations, single-point indications or taggings can be
routed on the positions “<user-defined>” as “Destination system interface” using the
DIGSI Configuration matrix.
• Registers 10122 to 10129 are available with 7UM62 V4.10 or higher.
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10116 SGF100 Alarm 1 = Stator ground fault prot. 100%: Alarm stage 5487
10117 SGF100 TRIP 1 = Stator ground fault prot. 100%: TRIP 5489
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10118 64R-1_3Hzpickup 1 = 64R-1 (1-3Hz) picked up (Alarm) 5403
10119 64R-2_3Hz TRIP 1 = 64R-2 (1-3Hz) TRIP 5407
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10120 87N picked up 1 = 87N picked up 5817
10121 87N TRIP 1 = 87N TRIP 5821
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10122 Failure SGF 1 = Failure stator ground fault prot. 100% 5486
10123 Failure 64R 1 = Failure 64R: measuring circuit 5400
10124 Fail 64R 1-3Hz 1 = Failure 64R protection (1-3Hz) 5401
10125 <user-defined> not pre-allocated -
10126 <user-defined> not pre-allocated -
10127 <user-defined> not pre-allocated -
10128 <user-defined> not pre-allocated -
10129 <user-defined> not pre-allocated -
