3.4.8 Registers 40601 to 40626: Event recorder (Sequence of Events)
• Registers are write-protected (with the exception of “SOE_Control”).
1
• Information regarding the individual information in the handshake register, the data
type “Message block” and the evaluation of Event recorder entries you find in the
manual “SIPROTEC Communication module, Modbus - Communication profile”
(ref. to page i).
• Only the annunciation “Data invalid” (ref. to chap. 3.4.3) is routed per default to the
Event recorder.
Further annunciations can be added to the Event recorder using DIGSI (ref. to chap.
“Customization of the allocations” in the manual “SIPROTEC Communication
module, Modbus - Communication profile”).
1. A write access is rejected with exception code 03 (ILLEGAL_DATA_VALUE).
Register Designation Comments
40601 No. of Event recorder entries Number of Event recorder entries which still were not read
40602 “SOE_Control” Handshake register (read/write access)
40603
Message block #1
Register type / Bit offset #1
40604 Register address #1
40605 Message cause / Indication type #1
40606 Value #1
40607
-
40610
Time stamp #1
40611
Message block #2
Register type / Bit offset #2
40612 Register address #2
40613 Message cause / Indication type #2
40614 Value #2
40615
-
40618
Time stamp #2
40619
Message block #3
Register type / Bit offset #3
40620 Register address #3
40621 Message cause / Indication type #3
40622 Value #3
40623
-
40626
Time stamp #3
