Siemens SIPROTEC4 7UM62 - Input Status Registers (1 X References); Registers 10001 to 10008: User-Defined Annunciations; Registers 10009 to 10013: Overcurrent Time Protection I; Registers 10014 to 10019: Overcurrent Time Protection I

Standard mapping 3-1
2-4
SIPROTEC Modbus - Bus mapping 7UM62
C53000-L1840-C009-03
2.2 Input Status registers (1X references)
2.2.1 Registers 10001 to 10008: User-defined annunciations
• User-defined protection annunciations, single-point indications or taggings can be
routed on these register positions as “Destination system interface” using the
DIGSI Configuration matrix.
2.2.2 Registers 10009 to 10013: Overcurrent time protection I>
2.2.3 Registers 10014 to 10019: Overcurrent time protection I>>
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10001 <user-defined> not pre-allocated -
10002 <user-defined> not pre-allocated -
10003 <user-defined> not pre-allocated -
10004 <user-defined> not pre-allocated -
10005 <user-defined> not pre-allocated -
10006 <user-defined> not pre-allocated -
10007 <user-defined> not pre-allocated -
10008 <user-defined> not pre-allocated -
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10009 50/51-1 Ph A PU 1 = 50/51-1 Phase A picked up 1811
10010 50/51-1 Ph B PU 1 = 50/51-1 Phase B picked up 1812
10011 50/51-1 Ph C PU 1 = 50/51-1 Phase C picked up 1813
10012 V< seal in 1 = 50/51-1 undervoltage seal-in 1970
10013 50/51 TRIP 1 = 50/51 I> TRIP 1815
Register
Designation of the
SIPROTEC objects
Comments
Internal
object no.
10014 67 forward 1 = 67 I>> direction forward 1806
10015 67 backward 1 = 67 I>> direction backward 1807
10016 50/51-2 Ph A PU 1 = 50/51-2 Phase A picked up 1801
10017 50/51-2 Ph B PU 1 = 50/51-2 Phase B picked up 1802
10018 50/51-2 Ph C PU 1 = 50/51-2 Phase C picked up 1803
10019 51/67 TRIP 1 = 50/51/67 I>> TRIP 1809
