⑨/⑩ Hook the feeder into the upper hooking position of the motor starter protector, and swivel the feeder to the busbar
adapter.
⑪ Screw the left-hand contactor tight diagonally into the openings provided using two M4 screws, plain washers and
spring washers.
Tightening torque: 1.5 ... 1.6 Nm
⑫ Screw the right-hand contactor tight diagonally into the openings provided using two M4 screws, plain washers and
spring washers.
Tightening torque: 1.5 ... 1.6 Nm
⑬ Insert the connecting cables into the corresponding main conductor terminals. Screw the main conductor terminals
tight.
