Figure C-23 Reversing starter S0, screw-type connection system, DIN-rail adapter 3RA2922‑1BA00
3RA2 fuseless load feeders – Size S3 for DIN rail
Note
The following versions of the fuseless load feeder are not available as 3RA2 pre-assembled
combinations.
Dimension drawings (dimensions in mm)
C.2 3RA2 fuseless load feeders – Size S00 to S3 for DIN rail
SIRIUS 3RA Load Feeders
154 Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004
