C.3 3RA2 fuseless load feeders – Size S00 to S2 for 60 mm busbar
systems
3RA2 fuseless load feeders – Size S00 for 60 mm busbar systems
Figure C-26 S00 direct-on-line starter, AC/DC, screw-type connection system 3RA2110-..D
Figure C-27 S00 reversing starter, AC/DC, screw-type connection system3RA2210-..D
Dimension drawings (dimensions in mm)
C.3 3RA2 fuseless load feeders – Size S00 to S2 for 60 mm busbar systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 157
