3RA2 fuseless load feeders – Size S0 for 60 mm busbar systems
Figure C-30 S0/S0 and S00/S0 direct-on-line starters, AC, screw-type connection
system3RA2120-..D..-0AP0
Figure C-31 S0/S0 and S00/S0 reversing starters, AC, screw-type connection system3RA2220-..D..-0AP0
Dimension drawings (dimensions in mm)
C.3 3RA2 fuseless load feeders – Size S00 to S2 for 60 mm busbar systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 159
