Mounting the direct-on-line starter (with soft starter) on the DIN rail adapter: Size S2
The gure below illustrates how the size S2 direct-on-line starter (with soft starter) with screw-
type connection system is mounted on a DIN rail adapter. The devices are snapped onto the DIN
rail adapter and screwed onto the adapter.
① Place the adapter plate on the DIN rail adapter.
② Screw the adapter plate to the DIN rail adapter.
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
